Seznam velikostí potrubí Hdpe:
| Specifikace | SDR26 0,6 MPa | SDR21 0,8 MPa | SDR17 1,0 MPa | SDR13.6 1,25 MPa | SDR11 1,6 MPa |
| DN (mm) | tloušťka (mm) | tloušťka (mm) | tloušťka (mm) | tloušťka (mm) | tloušťka (mm) |
| 20 | - | - | - | - | 2.3 |
| 25 | - | - | - | - | 2.3 |
| 32 | - | - | - | - | 3.0 |
| 40 | - | - | - | - | 3.7 |
| 50 | - | - | - | - | 4.6 |
| 63 | - | - | 4.7 | 5.8 | |
| 75 | - | - | 4.5 | 5.6 | 6.8 |
| 90 | 4.3 | 5.4 | 6.7 | 8.2 | |
| 110 | 4.2 | 5.3 | 6.6 | 8.1 | 10,0 |
| 125 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 |
| 140 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 |
| 160 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 |
| 180 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 |
| 200 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 8.6 | 10.8 | 13.4 | 16.6 | 20.5 |
| 250 | 9.6 | 11.9 | 14.8 | 18.4 | 22.7 |
| 280 | 10.7 | 13.4 | 16.6 | 20.6 | 25.4 |
| 315 | 12.1 | 15.0 | 18.7 | 23.2 | 28.6 |
| 355 | 13.6 | 16.9 | 21.1 | 26.1 | 32.2 |
| 400 | 15.3 | 19.1 | 23.7 | 29.4 | 36.3 |
| 450 | 17.2 | 21.5 | 26.7 | 33.1 | 40,9 |
| 500 | 19.1 | 23.9 | 29.7 | 36.8 | 45.4 |
| 560 | 21.4 | 26.7 | 33.2 | 41.2 | 50,8 |
| 630 | 24.1 | 30,0 | 37.4 | 46.3 | 57.3 |
| 710 | 27.2 | 33.9 | 42.1 | 52.2 | - |
| 800 | 30.6 | 38.1 | 47.4 | 58,0 | - |
| 900 | 34.4 | 42,9 | 53.3 | - | - |
| 1000 | 38.2 | 44.7 | 59.3 | - | - |
Čína výrobce hdpe potrubí iso4427 standardní potrubí, jakýkoli dotaz, neváhejte nás připojit
E-mail: sales2@kangyugy.com.
Populární Tagy: Hdpe Pipe, Čína, výrobci, dodavatelé, velkoobchod, přizpůsobení
